Victoria Dock Portal
Services: Architecture, MEP | Studio: Atkins | Client: Vinci (Taylor Woodrow) | Year: 2015 - 2016 | Software: MicroStation, Architecture, Mechanical Systems, Structural Modeler, Navigator, ProjectWise | Stage: 5 - 7 (H - L) | Location: London
Two buildings built on top of a reinforced concrete portal structure for the Elizabeth line. This consisted of a Head House building (service room). The design included emergency Intervention and Escape structure which provided access from the main rail platform.
Running clash detection between multi-discipline models and creating a report. Ensuring all elements in 3D model have datasets applied and created with BIM tools which complied with standards. Utilizing Dataset Explorer to generate correct graphical presentation of 2D extractions.
